Polypac Chemical Resistant Rod Seal

Polypac Chemical Resistant Rod Seal provides reliable, long-lasting sealing for hydraulic rods operating in aggressive chemical environments. Made from PTFE-filled compounds and compatible elastomers, these seals offer low friction, excellent wear resistance, and customizable sizes for demanding applications.

Get a free quote

Product Description

Overview

Polypac Chemical Resistant Rod Seal is specially designed to protect hydraulic rods and pistons in systems exposed to aggressive chemicals, solvents, acids, and high-wear conditions. Built on Polypac’s decades of sealing expertise, this seal combines advanced PTFE-filled materials with engineered elastomers to deliver consistent performance and long service life.

Key Features

Exceptional chemical resistance against acids, alkalis, solvents, and hydraulic fluids
Low friction and smooth operation to reduce wear and energy loss
High wear and extrusion resistance for long-lasting reliability
Wide temperature range for harsh working conditions
Available in PTFE-filled variants (bronze, carbon, graphite, MoS2, glass) and common elastomers (NBR, FKM, EPDM, silicone, FFKM)

Why Choose Polypac

Polypac is a professional hydraulic seal manufacturer and oil seal supplier with a 10,000+ m² production base and advanced testing equipment. Founded in 2008, we started with filled PTFE seals and have since expanded to O-rings and custom rubber rings. We collaborate with universities and research institutions to ensure product quality and continuous improvement.

Proven Materials and Manufacturing

Our Chemical Resistant Rod Seals use proven filled PTFE compounds for superior chemical stability and low friction. Elastomer options are selected to match system fluids and temperatures, ensuring tight sealing without compromising flexibility.

Custom Solutions and Testing

Polypac offers custom sizes, profiles, and material blends to meet unique application needs. All seals undergo strict quality checks and performance testing to ensure they meet industry standards and real-world demands.

Applications

Ideal for hydraulic cylinders, pumps, valves, and actuators in industries such as chemical processing, oil & gas, marine, mining, and manufacturing where chemical exposure and abrasion are concerns.

Ordering & Support

Contact Polypac for sample parts, material recommendations, and custom quotes. Our technical team helps select the right seal design and material to maximize uptime and reduce maintenance costs.

Product Images

Question you may concern

How do I choose the right material for my sealing application?

Material selection depends on four key factors: Media: What fluid or gas will the seal contact? (e.g., petroleum oil, water, chemicals, steam) Temperature: What is the minimum and maximum operating temperature? Pressure: What is the system's operating pressure? Are there pressure spikes? Application: Is it a static, dynamic, or rotary seal? Example: NBR (Buna-N) is excellent for standard hydraulic oil, while FKM (Viton®) is needed for high temperatures or aggressive chemicals.

What is the difference between a static seal and a dynamic seal?

A Static Seal is used between two surfaces that do not move relative to each other (e.g., pipe flanges, end caps). O-rings and gaskets are common static seals. A Dynamic Seal is used between surfaces that do move (e.g., piston and cylinder, rotating shaft). Rod seals, piston seals, and rotary shaft seals are designed for this purpose.

What does "AS568" mean?

AS568 is the Aerospace Standard that defines the dimensions for over 360 standard O-ring sizes. It is the most widely accepted sizing system in North America and globally. An AS568 number (e.g., AS568-214) specifies a precise inside diameter and cross-section.

How important is surface finish on the metal parts that contact the seal?

Extremely important. A rough surface will abrade and wear out the seal quickly, causing leaks. A finish that is too smooth can prevent a lubricating film from forming. A typical recommended surface finish for dynamic applications is 0.2 to 0.8 μm (8-32 μin) Ra.
